BS/DIN Roller Chainpublic/images/products/chains-sprockets/type-1.png
BS/DIN Roller Chain
British Standard roller chain in simplex, duplex, and triplex configurations for industrial drives.
Chains & Sprockets Supplier UAE | Roller Chain & Drive Components
Roller chain, sprockets, and drive components for UAE factories and conveyors. Contact us with pitch, strand, and bore for a quote.
One accountable partnerUAE executionInternational manufacturing reach
Chains & Sprockets Range
Types of chains & sprockets we supply
Each type below covers a different application — browse the range, then send the specs listed in the quote guide.
ANSI Roller Chainpublic/images/products/chains-sprockets/type-2.png
ANSI Roller Chain
American Standard chain for equipment imported from US manufacturers or OEM specs.
Sprockets — Finished Borepublic/images/products/chains-sprockets/type-3.png
Sprockets — Finished Bore
Pre-bored sprockets with keyway for direct shaft mounting on maintenance replacements.
Sprockets — Taper Lockpublic/images/products/chains-sprockets/type-4.png
Sprockets — Taper Lock
Sprockets with taper bush mounting for accurate fit and easy removal during maintenance.
Heavy-Duty & Attachment Chainpublic/images/products/chains-sprockets/type-5.png
Heavy-Duty & Attachment Chain
Extended pin, conveyor, and attachment chain for specialized conveying applications.
Chain Accessoriespublic/images/products/chains-sprockets/type-6.png
Chain Accessories
Connecting links, offset links, tensioners, and lubricants for chain drive maintenance.
Quote Faster
What we need to quote your chains & sprockets order
Follow this flow to send complete specifications — fewer back-and-forth messages, faster quotes.
1
Choose product type
Pick the type that matches your application from the range above.
2
Gather specifications
Confirm dimensions, standards, brand preference, and quantity.
3
Send your enquiry
Share details via our quote form or WhatsApp — photos and part numbers help.
4
Receive your quote
We verify specs and respond on business days, usually same day.
What to include
Details we need for a fast chains & sprockets quote
- Chain pitch (e.g. 06B, 08B, 10B, 12B or ANSI equivalent)
- Number of strands (simplex / duplex / triplex)
- Length in meters or number of links
- Sprocket teeth count, pitch, and bore if needed
- Qty + application + lubrication environment
Example enquiries
Roller chain 08B-1, 5 metersSprocket 08B, 25 teeth, 25 mm boreDuplex chain 12B-2, 3 meters10B sprocket 30T, TL 2012, 50 mm boreBy product type
Key specs to confirm per type
BS/DIN Roller Chain
- BS 06B–32B
- DIN 8187
- ISO 606
ANSI Roller Chain
- ANSI 25–160
- ISO 606 equivalent tables
Sprockets — Finished Bore
- BS/ANSI sprocket standards
- Pilot and finished bore options
Sprockets — Taper Lock
- Taper lock series 1008–5050
- BS/ANSI pitch matched
Heavy-Duty & Attachment Chain
- Attachment series per pitch
- Custom link spacing on request
Chain Accessories
- OEM and standard series
- Spring clip and cotter pin types
Chains & Sprockets Types
Chains & Sprockets for UAE factories
BS/DIN Roller Chain
British Standard roller chain in simplex, duplex, and triplex configurations for industrial drives.
ANSI Roller Chain
American Standard chain for equipment imported from US manufacturers or OEM specs.
Sprockets — Finished Bore
Pre-bored sprockets with keyway for direct shaft mounting on maintenance replacements.
Sprockets — Taper Lock
Sprockets with taper bush mounting for accurate fit and easy removal during maintenance.
Heavy-Duty & Attachment Chain
Extended pin, conveyor, and attachment chain for specialized conveying applications.
Chain Accessories
Connecting links, offset links, tensioners, and lubricants for chain drive maintenance.
Brands
Brands & series we source
Tsubaki / Renold equivalents
Premium chain for high-duty conveyors and continuous operation.
Standard BS/DIN roller chain
Cost-effective MRO supply for general industrial drives.
Stainless steel chain
Food, chemical, and washdown environments requiring corrosion resistance.
Catalogue
Chains & Sprockets — standard configurations
Common chain and sprocket configurations. Contact us with pitch, strand count, and bore for a quote.
Roller Chain
Standard BS roller chain lengths for conveyor and drive applications.
| Designation | Profile | Pitch / OD | Grooves / Strands | Bush / max bore | Enquire |
|---|---|---|---|---|---|
| 06B-1 × 5 m | BS roller chain 9.525 mm pitch | Simplex / 1 strand | — | Connecting link included | |
| 08B-1 × 5 m | BS roller chain 12.7 mm pitch | Simplex / 1 strand | — | Connecting link included | |
| 10B-1 × 5 m | BS roller chain 15.875 mm pitch | Simplex / 1 strand | — | Connecting link included | |
| 12B-2 × 3 m | BS roller chain 19.05 mm pitch | Duplex / 2 strand | — | Connecting link included | |
| 16B-1 × 3 m | BS roller chain 25.4 mm pitch | Simplex / 1 strand | — | Connecting link included | |
| 20B-1 × 3 m | BS roller chain 31.75 mm pitch | Simplex / 1 strand | — | Connecting link included |
Sprockets
Matched sprockets with finished or taper lock bores.
| Designation | Profile | Pitch / OD | Grooves / Strands | Bush / max bore | Enquire |
|---|---|---|---|---|---|
| 08B-25T / 25 mm | BS sprocket 12.7 mm pitch | 25 teeth | Simplex | 25 mm finished bore | |
| 08B-30T / 30 mm | BS sprocket 12.7 mm pitch | 30 teeth | Simplex | 30 mm finished bore | |
| 10B-25T / 35 mm | BS sprocket 15.875 mm pitch | 25 teeth | Simplex | 35 mm finished bore | |
| 12B-19T / TL 2012 | BS sprocket 19.05 mm pitch | 19 teeth | Simplex | 2012 / 50 mm | |
| 12B-25T-D / TL 2517 | BS sprocket 19.05 mm pitch | 25 teeth | Duplex | 2517 / 60 mm | |
| 16B-21T / TL 3020 | BS sprocket 25.4 mm pitch | 21 teeth | Simplex | 3020 / 75 mm |
Chain Accessories
Links, tensioners, and maintenance items for chain drives.
| Designation | Profile | Pitch / OD | Grooves / Strands | Bush / max bore | Enquire |
|---|---|---|---|---|---|
| 08B connecting link | BS chain connecting link | 12.7 mm pitch | Simplex | Spring clip type | |
| 10B offset link | BS chain offset link | 15.875 mm pitch | Simplex | For odd link counts | |
| 08B chain tensioner | Adjustable chain tensioner | 08B compatible | — | Bracket mount | |
| 12B roller chain lubricant | Chain lubricant 5 L | All BS pitches | — | Penetrating formula |
Live stock confirmation is always required before order. Share designation, quantity, and application for the fastest specification check.
Specifications
Technical specifications
| Parameter | Options / Notes |
|---|---|
| Pitch | 06B, 08B, 10B, 12B, 16B, 20B and ANSI 25–160 equivalents |
| Strands | Simplex (1), Duplex (2), Triplex (3) |
| Material | Carbon steel standard; stainless steel on request |
| Sprocket bore | Pilot bore, finished bore with keyway, taper lock bush |
| Standards | BS 228, DIN 8187, ANSI B29.1, ISO 606 |
Guides
Sizing references
Roller Chain Pitch Guide
Match chain pitch to sprocket and drive requirements using BS and ANSI tables.
Read guide →Sprocket Teeth & Bore Selection
Confirm drive ratio, minimum teeth, and shaft fit before ordering.
Read guide →Simplex vs Duplex Chain Drives
Choose strand count based on torque and sprocket width.
Read guide →
Why Sidrat
Chains & Sprockets supply for UAE factories
- Chain and sprocket supply for UAE factories and conveyors.
- Matching chain, sprockets, and accessories from one RFQ.
- Heavy-duty and stainless options on request.
- Contact us for any pitch or bore not listed.
Need chains & sprockets for your factory?
Contact us with part details — listed or not. Same-day response on business days.
